大型液壓系統核心工藝如何加工呢？

大型液壓系統缸筒內孔精加工的方法，主要有如下幾種：

精車或鏜孔、鉸孔加工、內孔磨削、滾壓成形、珩磨等。

1、精車或鏜孔：單點接觸（切削大）、時間長、成本高、精度低、表面粘削。

2、鉸孔加工：多刃鉸刀、排削困難，緊給率低，加工時間長，不適合于大孔、長孔的加工，目前的工藝能力更不適用于缸筒內孔的加工。

3、內孔磨削：線接觸、切削力不均勻，加工長孔比較困難，裝夾對中困難，表面燒損，表面加工不均勻等。

4、滾壓成形：工藝特性決定了該方法不適合于高精度要求的伺服油缸缸筒的內孔加工，對于其它類型缸筒加工，加工效率較理想。

5、珩磨：

A、改善幾何形狀（粗珩后的圓度、直線度、圓柱度均在0.01mm內，精珩后均可到0.001mm以內）和表面結構組織（生成帶角度的螺旋交叉網紋，行程了具有很好的潤滑效果的潤滑油膜表面），而且可去除鑽削、鉸削和內圓磨所産生的殘馀應力；

B、珩磨的精髓在于油石、芯軸、珩磨油、珩磨壓力、珩磨速度。

大型液壓缸是將液壓能轉變爲機械能的、做直線往複運動（或擺動運動）的液壓執行元件。它結構簡單、工作可靠。用它來實現往複運動時，可免去減速裝置，并且沒有傳動間隙，運動平穩，因此在各種機械的液壓系統中得到廣泛應用。液壓缸輸出力和活塞有效面積及其兩邊的壓差成正比； 液壓缸基本上由缸筒和缸蓋、活塞和活塞桿、密封裝置、緩沖裝置與排氣裝置組成。緩沖裝置與排氣裝置視具體應用場合而定，其他裝置則必不可少。
